    UL20346

    Ask Lasest Price
    Brand Name : WCH Cable
    Model Number : UL20346
    Certification : UL, Cul, AWM
    Price : USD0.03-0.32 per meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5,000,000 meters per Month
    Delivery Time : 9 days for ready goods
    • Product Details
    • Company Profile

    UL20346

    UL20346 Ribbon Cable
    Conductor: High Purity Copper Wire
    Rated temperature: -30℃ to 105℃
    Rated voltage: 300V
    Insulation: Eco-friendly Thermoplastic Elastomer TPE
    Jacket: Eco-friendly Thermoplastic Elastomer TPE
    Feature: UL & CSA Approval, RoHS Guaranteed.
    Reference Standard: UL758, UL1581, CSA22.2.
    Style Number: UL20346
    Manufacturer: WCH Cable Industrial Co., Ltd.
    Origin: Dongguan, China
    Custom Make Service is Available.
    Please consult our customer service for discussion of what you like.

    WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly


    Technical Parameters
    ConductorCores Number 2-68 Pins
    Specification(AWG)30
    Section Area(mm²)0.051
    Material Solid tinned copper
    Configuration(mm)TS1/0.254
    Stranded Diameter(mm)0.254
    InsulationAve Thickness(mm)0.18
    Min Thickness(mm)0.15
    Over Diameter(mm)0.635*43.18
    Material TPE (RoHS)
    Colour Gray
    Copper FoilMaterial One-side Copper Foil
    JacketAve Thickness(mm)0.41
    Min Thickness(mm)0.33
    Over Diameter(mm)1.52x44.2
    Material TPE (RoHS)
    Colour Gray
    Electrical
    Capability
    Rated Temperature(℃)105
    Rated Voltage(V)300
    Conductor Resistance(Ω/KM 20℃)361
    Insulation Resistance(MΩ/KM 20℃)10
    Other
    Properties
    Fire Retardance VW-1
    UL Style Number 20346
    Environmental Standard Lead Free
      RoHS & Reach Compliant
