300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White

WCH Cable Industrial Co., Ltd.
Contact Now
    Buy cheap 300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White from wholesalers

    Buy cheap 300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White from wholesalers
    • Buy cheap 300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White from wholesalers

    300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White

    Ask Lasest Price
    Brand Name : WCH Cable
    Model Number : SJTOOW 12AWG 3C OD11.00 WHT
    Certification : UL & CUL Certificate
    Price : USD0.2088
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000000 meters per month
    Delivery Time : 9 days for ready goods
    • Product Details
    • Company Profile

    300V UL Power Cord Cable SJTOOW 12AWG 3C STR Conductors OD11.0mm TPE White


    ConductorSpecification(AWG)12
    Section Area(mm²)5.2698
    Material Bare Stranded Copper
    Configuration(mm)AS65/0.254±0.008
    Conductor Quantity 3C
    InsulationAverage Thickness(mm)0.76
    Minimum Thickness(mm)0.65
    Over Diameter(mm)4.00±0.20
    Material TPE (RoHS)
    Colour Black, Red, Yellow
    JacketAverage Thickness(mm)1.14
    Minimum Thickness(mm)0.91
    Overall Diameter(mm)11.00±0.30
    Material TPE (RoHS)
    Colour White
    Electrical
    Capability
    Rated Temperature(℃)105
    Rated Voltage(V)300
    Rated Currency(A)20
    Conductor Resistance(Ω/KM 20℃)5.64
    Insulation Resistance(MΩ/KM 20℃)100
    FlammabilityFire Retardance VW-1
      CUL FT1
    ApprovalUL Style Number SJTOOW
    Reference Standard UL 62
    Environmental Standard Lead Free
      RoHS & Reach Compliant
