UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V
TPU Curly Cable is the most featured product of WCH Cable. Fast resilience, easy working, long flex life, are the outstanding characteristic of WCH Cable tpu curly cable. Below is one of the example. More custom item or designated properties, please contact WCH Cable staff to get it.
Spiral coiling diagram:
Product parameters:
| Spiral Cable Construction | Spiral Length (unexpanded) | (mm) | 300 |
| Straight Ends | (mm/mm) | 200/200 | |
| Extension Ratio | 1 : 4 | ||
| Spiral Outer Ø | (mm) | 25 | |
| Tail Angle | 90 degree | ||
| End Treatment | Cut Flat | ||
| Electrical Capability | Working Voltage | (V) | 30 |
| Temp Range | (°C) | -40 to +80 | |
| Test Voltage | (V) | 2000/3000 | |
| Nominal Voltage | (V) | 30 | |
| Conductor Resistance | (Ω/KM 20°C) | 239 | |
| Insulation Resistance | (MΩ/KM 20°C) | 100 | |
| Standard & Use | UL Marking | Per UL21686 | |
| CUL Standard | I/II A | ||
| Flammability | VW-1, FT1 | ||
| Raw Cable Construction | Conductor Size | (AWG) | 28 |
| Insulation Material | PP (RoHS) | ||
| Insulation Diameter | (mm) | 0.90 | |
| Conductor Quantity | 13 Cores | ||
| Assembly | Stranded in layers | ||
| Overall Diameter | (mm) | 6.00 | |
| Jacket Material | Extruded TPU (RoHS) | ||
| Surface Effect | Matt Black |
UL21686 TPU Sheathed Cable 80C 30V
| Style Number | Core Quantity | Conductor Size | Conductor Strands | Insulation Thickness | Insulation Diameter | Jacket Thickness | Overall Diameter | Conductor Resistance |
| AWG | No/mm | mm | mm | mm | mm | Ω/KM | ||
| UL21686 | 2C | 30 | 7/0.100 | 0.23 | 0.80 | 0.38 | 3.20 | 381.00 |
| 2C | 28 | 7/0.127 | 0.23 | 0.90 | 0.38 | 3.40 | 239.00 | |
| 2C | 26 | 7/0.16 | 0.23 | 1.00 | 0.38 | 3.60 | 150.00 | |
| 2C | 24 | 11/0.16 | 0.23 | 1.10 | 0.38 | 3.80 | 94.20 | |
| 2C | 22 | 17/0.16 | 0.23 | 1.30 | 0.38 | 4.20 | 59.40 | |
| 2C | 20 | 21/0.178 | 0.23 | 1.50 | 0.38 | 4.60 | 36.70 | |
| 2C | 18 | 34/0.178 | 0.23 | 1.80 | 0.38 | 5.20 | 23.20 | |
| 2C | 16 | 26/0.25 | 0.23 | 2.00 | 0.38 | 5.80 | 14.60 | |
| 3C | 30 | 7/0.100 | 0.23 | 0.80 | 0.38 | 3.40 | 381.00 | |
| 3C | 28 | 7/0.127 | 0.23 | 0.90 | 0.38 | 3.50 | 239.00 | |
| 3C | 26 | 7/0.16 | 0.23 | 1.00 | 0.38 | 3.80 | 150.00 | |
| 3C | 24 | 11/0.16 | 0.23 | 1.10 | 0.38 | 4.00 | 94.20 | |
| 3C | 22 | 17/0.16 | 0.23 | 1.30 | 0.38 | 4.40 | 59.40 | |
| 3C | 20 | 21/0.178 | 0.23 | 1.50 | 0.38 | 4.80 | 36.70 | |
| 3C | 18 | 34/0.178 | 0.23 | 1.80 | 0.38 | 5.50 | 23.20 | |
| 4C | 30 | 7/0.100 | 0.23 | 0.80 | 0.38 | 4.80 | 381.00 | |
| 4C | 28 | 7/0.127 | 0.23 | 0.90 | 0.38 | 5.10 | 239.00 | |
| 4C | 26 | 7/0.16 | 0.23 | 1.00 | 0.38 | 5.30 | 150.00 | |
| 4C | 24 | 11/0.16 | 0.23 | 1.10 | 0.38 | 5.50 | 94.20 | |
| 4C | 22 | 17/0.16 | 0.23 | 1.30 | 0.38 | 6.00 | 59.40 | |
| 4C | 20 | 21/0.178 | 0.23 | 1.50 | 0.38 | 6.50 | 36.70 | |
| 5C | 30 | 7/0.100 | 0.23 | 0.80 | 0.38 | 5.00 | 381.00 | |
| 5C | 28 | 7/0.127 | 0.23 | 0.90 | 0.38 | 5.30 | 239.00 | |
| 5C | 26 | 7/0.16 | 0.23 | 1.00 | 0.38 | 5.60 | 150.00 | |
| 5C | 24 | 11/0.16 | 0.23 | 1.10 | 0.38 | 5.80 | 94.20 | |
| 5C | 22 | 17/0.16 | 0.23 | 1.30 | 0.38 | 6.40 | 59.40 | |
| 6C | 30 | 7/0.100 | 0.23 | 0.80 | 0.38 | 5.30 | 381.00 | |
| 6C | 28 | 7/0.127 | 0.23 | 0.90 | 0.38 | 5.60 | 239.00 | |
| 6C | 26 | 7/0.16 | 0.23 | 1.00 | 0.38 | 5.90 | 150.00 | |
| 6C | 24 | 11/0.16 | 0.23 | 1.10 | 0.38 | 6.20 | 94.20 |
