UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V

WCH Cable Industrial Co., Ltd.
Contact Now
    Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers

    Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers
    • Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers
    • Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers
    • Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers
    • Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers
    • Buy cheap UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V from wholesalers

    UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V

    Ask Lasest Price
    Brand Name : WCH Cable
    Model Number : WCH-UL3122
    Certification : UL Certificate
    Price : USD 0.05 per meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4000000 meters per month
    Delivery Time : 9 days for ready goods
    • Product Details
    • Company Profile

    UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V

    UL3122 Fiberglass Braided Electrical Silicone Rubber Wire Rated 200℃ 300V

    High purity of copper wire conductors
    Conductor size: 26AWG ~ 16AWG
    Tinned annealed or bare, stranded or solid copper conductor.
    Silicone rubber insulation.
    Rated temperature 200℃.
    Rated voltage 300V.
    Uniform wall thickness of insulation for easy stripping and cutting.
    UL VW-1 and CUL FT1 flame test verified.
    Top coated conductor is available.



    UL Style& Cul TypeConductorInsulation
    Thickness
    Overall
    Diameter
    Standard Put-upConductor
    Resistance
    AWGNo/mmmmmmFeet/reelMeter/reelΩ/KM
    UL3122
    CUL AWM I A
    (Stranded)
    267/0.160.381.552000610150
    247/0.200.381.70200061094.2
    11/0.160.381.702000610
    227/0.250.381.85200061059.4
    17/0.160.381.852000610
    207/0.310.382.05200061036.70
    21/0.1780.382.052000610
    187/0.390.382.28200061023.20
    34/0.1780.382.282000610
    167/0.500.382.63200061014.60
    26/0.250.382.632000610
    UL3122
    CUL AWM I A
    (Solid)
    261/0.390.381.552000610140
    241/0.500.381.62200061087.5
    221/0.640.381.75200061055.0
    201/0.810.381.92200061034.6
    181/1.020.382.12200061021.8
    161/1.290.382.43200061013.7
